NOT 220 UP
RWS emergency push button for opening a sliding or swing door in an emergency
LED lighting for better visibility
Contact system consists of one normally closed contact and one normally opened contact
A second normally closed contact is available as an accessory
Ident-No. | Name | Description | Type of installation | IP rating | Operating voltage | Supply voltage | Dimensions |
|---|---|---|---|---|---|---|---|
| 210204 | NOT 220 UP emergency push button, Jung AS 500 | with 1-gang frame, Jung AS 500; with emergency exit sign arrow downwards; Operating voltage: 24 V DC; Contact current capacity: 3A, 250 V; 1 normally closed contact; 1 normally open contact | Flush-mounted installation | IP30 | 24 V DC | 24 V DC | 80.5 x 80.5 x 98 mm |
Select your desired system components here:
Accessories
Product Details
Technical data
Downloads
Application Areas
- Indirect release of GEZE emergency exit system door control units
- Opening of automatic doors in case of an emergency
- Flush-mounted installation makes almost flush integration possible with small installation height
