Scissors OL 90 N

Achieves the full opening width of 170 mm for all leaf heights

Little space necessary thanks to flat design of the scissors

Locking in the scissors guarantees a safe leaf locking mechanism

Unhinging inhibitor on the scissors offers additional safety

Scissor unhooking by pressing the release button facilitates window cleaning from inside and outside

Completely pre-mounted assembly groups facilitate installation

Choose variant

Only show differences

Ident-No.	Name	Description	Colour	Opening width (max.)	Type of stroke shortening	Leaf weight (max.)	Leaf width (max.)	Leaf width (min.)
030373	Scissors OL 90 N	with standard leaf bracket and achieves an opening width of 170 mm	EV1	170 mm	Mechanical	80 kg	1200 mm	380 mm
030376	Scissors OL 90 N	with standard leaf bracket and achieves an opening width of 170 mm	according to RAL	170 mm	Mechanical	80 kg	1200 mm	380 mm
030377	Scissors OL 90 N	with standard leaf bracket and achieves an opening width of 170 mm	white RAL 9016	170 mm	Mechanical	80 kg	1200 mm	380 mm
074509	Scissors OL 90 N	with standard leaf bracket and achieves an opening width of 170 mm	black	170 mm	Mechanical	80 kg	1200 mm	380 mm
