Closer body TS 4000 E
Main body for overhead door closer with link arm EN 1-6 with electric hold-open device
Closing force can be variably adjusted from the front
Visual closing force display ensures correct setting
Closing seed can be adjusted from the front via valve
Latching action can be adjusted via link arm
Electric hold-open device
Door closer, can be used for right and left hand doors
Ident-No. | Name | Description | Colour | Type of installation | IP rating | Adjustable closing speed | Input voltage | Standard conformity | Closing force in accordance with EN 1154 | Closing force adjustable | Back check integrated | Latching action adjustable | Visual closing force display | Leaf width (max.) | Hold-open function | Dimensions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 105211 | GEZE TS 4000 E door closer | Closing force EN 1-6, door leaf installation hinge side, with electric hold-open device and connector box (without link arm) | silver-coloured | Door leaf installation hinge side | IP43 | Yes | 24 V DC | EN 1154:1996/A1:2002/AC:2006. EN 1155 | EN 1 - 6 | Yes, stepless | No | Yes, via link arm | Yes | 1400 mm | Electrical | 325 x 46 x 60 mm |
| 105212 | GEZE TS 4000 E door closer | Closing force EN 1-6, door leaf installation hinge side, with electric hold-open device and connector box (without link arm) | according to RAL | Door leaf installation hinge side | IP43 | Yes | 24 V DC | EN 1154:1996/A1:2002/AC:2006. EN 1155 | EN 1 - 6 | Yes, stepless | No | Yes, via link arm | Yes | 1400 mm | Electrical | 325 x 46 x 60 mm |
Select your desired system components here:
Spare parts
Product Details
Technical data
Downloads
Application Areas
- Fire and smoke protection doors
- Right and left single-action doors
- Single-action doors up to 1400 mm leaf width
- Door leaf installation hinge side and transom installation opposite hinge side
