Slimchain 230 V
Chain drive in an attractive design with numerous possible applications in 230 V version
Can be integrated perfectly into the façade design thanks to its slim and discreet look
Fast and easy installation with the Smart fix installation system
Direct 230 V connection of the drive via a connection terminal with cable plug
Concealed 230 V line-feed
Direct access to the electronics for parameter setting via service cover
Drive stroke with variable adjustment
Ident-No. | Name | Colour | Length | Stroke | Description |
|---|---|---|---|---|---|
| 182570 | Slimchain L | EV1 | 478 mm | 200 mm | |
| 182571 | Slimchain L | white RAL 9016 | 478 mm | 200 mm | |
| 182582 | Slimchain R | EV1 | 478 mm | 200 mm | |
| 182583 | Slimchain R | white RAL 9016 | 478 mm | 200 mm | |
| 182584 | Slimchain L | EV1 | 528 mm | 300 mm | |
| 182585 | Slimchain L | white RAL 9016 | 528 mm | 300 mm | |
| 182586 | Slimchain R | EV1 | 528 mm | 300 mm | |
| 182587 | Slimchain R | white RAL 9016 | 528 mm | 300 mm | |
| 182588 | Slimchain L | EV1 | 628 mm | 500 mm | |
| 182589 | Slimchain L | white RAL 9016 | 628 mm | 500 mm | |
| 182590 | Slimchain R | EV1 | 628 mm | 500 mm | |
| 182591 | Slimchain R | white RAL 9016 | 628 mm | 500 mm | |
| 182592 | Slimchain L | EV1 | 778 mm | 800 mm | |
| 182593 | Slimchain L | white RAL 9016 | 778 mm | 800 mm | |
| 182594 | Slimchain R | EV1 | 778 mm | 800 mm | |
| 182595 | Slimchain R | white RAL 9016 | 778 mm | 800 mm | |
| 182596 | Slimchain - special version | according to RAL | Can be configured: Stroke, cable length, colour, version L/R |
Product Details
Downloads
Application Areas
- Natural ventilation in the façade area
- Inward- and outward-opening windows with bottom-hung, top-hung and side-hung leaves
- Outward opening projected top hung windows
- Installation on wooden, PVC or metal windows
- Leaf, frame or integrated installation
Falling window leaves can be a considerable risk to life and limb of persons in the vicinity. Therefore, the use of GEZE safety scissors is mandatory when using GEZE drives on bottom-hung windows.
